| 型号Type |
正向峰值 电流 Peak forward voltage |
正向峰值 电压 Peak forward voltage |
反向重复 峰值电流 Repetitive peak voltage |
反向重复 峰值电压 Repetitive peak current |
绝缘电压Insulation voltage | 工作结温Temperature rise | Fix power | Wind speed |
| (A) | (A) | (mA) | (V) | (V) | (℃) | (N.M.) | (m/s) | |
| UQD100A | 100 | ≥600 | ≤3 | ≤1.2 | 150 | ≤55 | ≥12.5 | 3.0 |
| UQD150A | 150 | ≥600 | ≤4 | ≤1.2 | 150 | ≤60 | ≥12.5 | 3.0 |
| UQD200A | 200 | ≥600 | ≤5 | ≤1.3 | 150 | ≤60 | ≥12.5 | 3.0 |
| UQD250A | 250 | ≥600 | ≤5 | ≤1.3 | 150 | ≤65 | ≥12.5 | 3.0 |
| UQD300A | 300 | ≥600 | ≤6 | ≤1.3 | 150 | ≤80 | ≥12.5 | 3.0 |
| UQD400A | 400 | ≥600 | ≤6 | ≤1.4 | 150 | ≤85 | ≥12.5 | 3.0 |
| UQD500A | 500 | ≥600 | ≤7 | ≤1.4 | 150 | ≤90 | ≥12.5 | 3.0 |
| 型号Type |
正向峰值 电流 Peak forward voltage |
正向峰值 电压 Peak forward voltage |
反向重复 峰值电流 Repetitive peak voltage |
反向重复 峰值电压 Repetitive peak current |
绝缘电压Insulation voltage | 工作结温Temperature rise | Fix power | Wind speed |
| (A) | (A) | (mA) | (V) | (V) | (℃) | (N.M.) | (m/s) | |
| UQS100A | 100 | ≥600 | ≤3.5 | ≤1.30 | 150 | ≤55 | ≥12.5 | 3.0 |
| UQS150A | 150 | ≥600 | ≤4.0 | ≤1.30 | 150 | ≤60 | ≥12.5 | 3.0 |
| UQS200A | 200 | ≥600 | ≤5.5 | ≤1.35 | 150 | ≤60 | ≥12.5 | 3.0 |
| UQS250A | 250 | ≥600 | ≤6.0 | ≤1.35 | 150 | ≤65 | ≥12.5 | 3.0 |
| UQS300A | 300 | ≥600 | ≤6.5 | ≤1.35 | 150 | ≤80 | ≥12.5 | 3.0 |
| UQS400A | 400 | ≥600 | ≤8.0 | ≤1.40 | 150 | ≤85 | ≥12.5 | 3.0 |
| UQS500A | 500 | ≥600 | ≤10.0 | ≤1.40 | 150 | ≤85 | ≥12.5 | 3.0 |
| UQS600A | 600 | ≥600 | ≤10.0 | ≤1.45 | 150 | ≤90 | ≥12.5 | 3.0 |
