特点

• 高性能/低损耗电路设计
• 2500Vrms光隔离
• “零压”型及调相“随机开关”型
• 高压（1200Vpk）型可用于480Vrms
• 控制输入LED指示器
• 控制电压范围：4-16Vdc，3-32Vdc或90-280Vac

选型指南

电压Voltage	控制电压Control voltage	额定工作电流Rated operational current
		10 Amp	15 Amp	25 Amp	40 Amp	60 Amp	80 Amp	100 Amp	120 Amp
280VAC "Zero Voltage"	4 to 16 Vdc	HDH1028ZD1	HDH1528ZD1	HDH2528ZD1	HDH4028ZD1	HDH6028RD1	HDH8028RD1	HDH10028RD1	HDH12028RD1
	3 to 32 Vdc	HDH1028ZD3	HDH1528ZD3	HDH2528ZD3	HDH4028ZD3	HDH6028RD3	HDH8028RD3	HDH10028RD3	HDH12028RD3
	90 to 280Vac	HDH1028ZA4	HDH1528ZA4	HDH2528ZA4	HDH4028ZA4	HDH6028RA4	HDH8028RA4	HDH10028RA4	HDH12028RA4
480VAC "Zero Voltage"	4 to 16 Vdc	HDH1048ZD1	HDH1548ZD1	HDH2548ZD1	HDH4048ZD1	HDH6048RD1	HDH8048RD1	HDH10048RD1	HDH12048RD1
	3 to 32 Vdc	HDH1048ZD3	HDH1548ZD3	HDH2548ZD3	HDH4048ZD3	HDH6048RD3	HDH8048RD3	HDH10048RD3	HDH12048RD3
	90 to 280Vac	HDH1048ZA4	HDH1548ZA4	HDH2548ZA4	HDH4048ZA4	HDH6048RA4	HDH8048RA4	HDH10048RA4	HDH12048RA4
Outline		D-1,6,7	D-1,6,7	D-1,6,7	D-1,6,7	D-1,6,7	D-1,6,7	D-1,6,7	D-1,2,6,7
