电流值：指集中电极直流(连续)电流
内部连线方式：T:桥臂连接；L:低端连接；H:高端连接；D:单管结构 封装形式：A:A-A-pak S:Int-A-pak D:Dual-Int-A-pak
电压量：集电极发射极电压值为:电压量×10(V)
类型：U型：超快速型 K:具有短路能力的超快速(NPT)
| Part Name | VCES | Ic@Tc | VCE(ON) | ICP | IGBT | Package | |
| V | A@25℃ | A@℃ | V | A | Type | ||
| HFGM75D06V1 | 600 | 100 | 75/70 | 1.9 | 140 | PT | V1 |
| HFGM100D06V1 | 600 | 130 | 100/70 | 2.2 | 200 | PT | V1 |
| HFGM150D06V1 | 600 | 200 | 150/70 | 1.9 | 350 | PT | V1 |
| HFGM200D06V2 | 600 | 260 | 200/70 | 2.2 | 400 | PT | V2 |
| HFGM75D06AV1 | 600 | 100 | 75/80 | 1.5 | 140 | Trench | V1 |
| HFGM100D06AV1 | 600 | 130 | 100/80 | 1.5 | 200 | Trench | V1 |
| HFGM150D06AV1 | 600 | 210 | 150/80 | 1.5 | 350 | Trench | V1 |
| HFGM200D06AV1 | 600 | 260 | 200/80 | 1.5 | 400 | Trench | V1 |
| HFGM200D06AV2 | 600 | 260 | 200/80 | 1.5 | 400 | Trench | V2 |
| HFGM300D06AV3 | 600 | 360 | 300/80 | 1.5 | 600 | Trench | V3 |
| HFGM400D06AV3 | 600 | 450 | 400/80 | 1.5 | 800 | Trench | V3 |
| HFGM75D12SV1 | 1200 | 100 | 75/80 | 2.8 | 200 | NPT | V1 |
| HFGM100D12SV1 | 1200 | 130 | 100/70 | 3.2 | 200 | NPT | V1 |
| HFGM150D12SV3 | 1200 | 200 | 150/70 | 2.8 | 350 | NPT | V3 |
| HFGM200D12SV3 | 1200 | 260 | 200/70 | 3.2 | 400 | NPT | V3 |
| HFGM100D12AV1 | 1200 | 130 | 100/80 | 1.7 | 200 | Trench | V1 |
| HFGM150D12AV3 | 1200 | 200 | 150/80 | 1.7 | 350 | Trench | V3 |
| HFGM200D12AV3 | 1200 | 260 | 200/80 | 1.7 | 400 | Trench | V3 |
| HFGM300D12AV3 | 1200 | 360 | 300/80 | 1.7 | 600 | Trench | V3 |
